HT
Vertical multi-stage stainless-steel centrifugal pumps
Designed to transfer clean water free from abrasive particles and liquids that will not damage the pump’s components. Their high efficiency and adaptability to a wide variety of applications make them an ideal choice in the domestic, civil, agricultural, and industrial sectors, particularly for water distribution along pressure tanks to increase overall network pressure. Suggested uses include fire-fighting systems, heavy-duty cleaning applications, industrial washing systems, and irrigation.
Flow rate | up to 800 l/min (48 m³/h) |
Head up | up to 160 m |
Manometric suction head | up to 7 m |
Liquid temperature | between -15 °C and +90 °C |
Ambient temperature | up to +40 °C |
Maximum working pressure | 16 bar |
Motor | 2 poles |
Ingress protection rating | IP X4 |
Pump housing | Cast iron JL250 |
Pump sleeve | Stainless steel AISI 304 |
Impellers | Stainless steel AISI 304 |
Diffusers | Stainless steel AISI 304 |
Shaft | Stainless steel AISI 431 |
Pump cover | Cast iron JL250 |
